DRY-BREAK Couplings TODO-MATIC

TODO-MATIC dry-break couplings are the product of over 30 years’ experience handling oil, gas and petrochemicals. This market-leading product was among the first to introduce the NATO STANAG 3756 standard and is recognised for its ability to handle a wide range of demanding applications.

Minimal residual loss and virtually zero spillage means operator safety is assured. Less leakage also means more product can be delivered to customers, translating to higher profit margins for the handler.

The TODO-MATIC coupling is recognised as a ‘best in class’ coupling and is used across many different sectors.

Available 1-6” sizes
High-grade materials
Minimum operator intervention required
Ability to handle aggressive fluids
Minimal residual loss and virtually zero spillage
Proven in the fiel

All TODO-MATIC dry-break couplings can be made to suit specific needs. We offer a range of different metal and O-ring grades to ensure no application is left beyond reach. For example, customers handling chemicals will benefit from 2” and 3” sizes configurations, while those working in offshore will opt for 4” and 6”.

Variant	Max Working Pressure	Product Test Pressure	Working Temperature Range	Certification	Mounting	Sizes	Materials	O-ring Grades	Options
TODO GAS	25 bar (363 psi)	37.5 bar (544 psi)	-20°C to +80°C (-4°F to +176°F) standard -45°C to +150°C (-49°F to +302°F) options	2014/68/EU - Pressure Equipment Directive (PED)	Thread or flanged variants available			Viton (FKM) 90 Shore	Pressure Equalisation Valve (PEV), colour coding, selectivity, caps and plugs, handle options
TODO 45	Up to 10 bar (580 psi)	Up to 15 bar (870 psi)	-20°C to +80°C (-4°F to +176°F)		Thread or flanged variants available	2.5" (DN65)	Aluminium, Stainless Steel	Viton (FKM), FMVQ
NGX	Up to 40 bar (580 psi)	Up to 60 bar (870 psi)	-20°C to +80°C (-4°F to +176°F)	2014/68/EU - Pressure Equipment Directive (PED)	Thread or flanged variants available	2" (DN50), 3" (DN80), 4" (DN100)	Aluminium, Stainless Steel	Viton (FKM), NBR, EPDM, Chemraz, Kalrez and many others
TODO MATIC	Up to 25 bar (363 psi)	Up to 37.5 bar (544 psi)	-20°C to +80°C (-4°F to +176°F) standard -45°C to +150°C (-49°F to +302°F) options	2014/68/EU - Pressure Equipment Directive (PED)	Thread or flanged variants available	1" (DN25), 2" (DN50), 2.5" (DN65), 3" (DN80), 4" (DN100), 6" (DN150)	Aluminium, Brass, Stainless Steel - others on request	Viton (FKM), NBR, EPDM, Chemraz, Kalrez and many others	Pressure Equalisation Valve (PEV), Colour coding, Selectivity, Caps and plugs, Locking mechanism, Magnetic switch, Rotational block, Handle options
NGX MARINE	Up to 40 bar (580 psi)	Up to 60 bar (870 psi)	-20°C to +80°C (-4°F to +176°F)			2" (DN50), 3" (DN80), 4" (DN100), 6" (DN150)	Stainless steel only	Nitrile (NBR or Buna), Viton (FKM), EPDM, Kalrez (FFKM), FMVQ, Chemraz (FFKM)	Threads: BSP (ISO 228), NPT (ANSI B1.20.1), others on request Flanges: PN10/16, PN25/40 (EN 1092-1), ANSI Class 150/300 (ANSI B16.5), others on request
PTC	Up to 25 bar (363 psi)		-20°C to +80°C (-4°F to +176°F)			2" (DN50), 3" (DN80), 4" (DN100)	Stainless steel only	Nitrile (NBR or Buna), Viton (FKM), EPDM, Kalrez (FFKM), FMVQ, Chemraz (FFKM)
FUEL NOZZLES	Up to 10 bar (145 psi)		-20°C to +80°C (-4°F to +176°F)			2" Body	Aluminium body, Brass attachments	Viton (FKM)	Threads: BSP (ISO 228), NPT (ANSI B1.20.1), others on request Specials: TODO Snap, W2" - 7
BALL VALVES	Up to 10 bar (145 psi)		-20°C to +80°C (-4°F to +176°F)			2" (DN50), 3" (DN80), 4" (DN100)	Aluminium	Nitrile (NBR or Buna), Viton (FKM), EPDM, Kalrez (FFKM), FMVQ, Chemraz (FFKM)	One-Way and Two-Way with manual or pneumatic operation Threads: BSP (ISO 228), NPT (ANSI B1.20.1), others on request Others: Blank flanged, TW, Weld end, Without connection
SWIVELS			-20°C to +80°C (-4°F to +176°F)			0.75" to 4"	Aluminium, Brass, Stainless Steel, others on request	Nitrile (NBR or Buna), Viton (FKM), EPDM, Kalrez (FFKM), FMVQ, Chemraz (FFKM)	Threads: BSP (ISO 228), NPT (ANSI B1.20.1), others on request Flanges: PN10/16 (ANSI B16.5), others on request
